DS-7608NXI-I2/8P/S(C)

Beschrijving

Specifications

8 IP camera inputs up to 12MP
Compression format H.265 / H.265 + / H.264 / H.264 + / MPEG4
Incoming bandwidth: 80 Mbps
Outgoing bandwidth: 256 Mbps
Video output VGA (1080P) and HDMI (4K)
BNC video output (1.0 Vp-p, 75Ω)
Two-way audio: 1 RCA input / 1 RCA output
Recording resolution: 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, UXGA, 720P, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF
8-channel synchro playback
Decoding capacity: 16 channels at 1080P
Intelligent analytics based on deep learning algorithm
Up to 4 channel facial recognition for facial images
Up to 1 channel facial recognition for video streaming
Face detection with face image comparison, face capture, face image search
Up to 16 libraries of facial images, with up to 10,000 images in total
Perimeter protection of up to 4 channels with recognition of vehicles and people and up to 12 rules
Supports various VCA (Video Content Analysis) events
POS information overlay on live view and image playback
Alarm triggering and alarm recording by POS event
Alarm channels: 4 inputs / 1 output
Storage: 2 SATA ports for disks up to 10TB (HDD not included)
Self-adaptive RJ45 (10/100 / 1000M) Ethernet network interface
Smart search for more efficient playback (for NEXTGEN IP cameras)
P2P in the cloud, DDNS DEMES, Push and channel zero
Plug & Play connection with NEXTGEN IP cameras
Connections: 1 USB 2.0, 1 USB 3.0
The rear panel incorporates 8 independent ports (10 / 100Mbps) PoE + 802.3af / at with a maximum consumption of ≤120W
Power supply: 100V ~ 240V AC, 50 / 60Hz
Consumption: ≤15W (without hard drives or PoE)
Operating temperature: -10 ° C ~ + 55 ° C
Relative humidity: 10 ~ 90%
Dimensions: 385 x 315 x 52mm (1U)
Weight: ≤2.7 kg
